algae density sensor josa cyano-0
Place of Origin: China
Brand Name: JIDE
Model Number: JOSA-Cyano

Description

JOSA-Cyano is an online water quality analyzer developed based on the JOSA optical water quality analysis platform. Highly sensitive photoelectric sensors capture weak fluorescence signals and convert them into chlorophyll a/algae density. Digital and intelligent sensor design concept.

Specifications

Model JOSA-Cyano
Measurement parameters Algae density (blue-green algae), temperature
Measurement method Fluorescence method
Range Algae density: (0~200000/2000000) Cells/mL;Temperature: (0~60) ℃
Accuracy ≤±3%
Repeatability ≤2%
Resolution 1Cells/mL
Detection limit 200Cells/mL
Response time ≤10s
Drift ≤±1%F.S.
Calibration cycle 6 months
Protection level IP68
Cleaning method Mechanical brush automatic cleaning
Communication RS485 (ModbusRTU), maximum baud rate 115200bps
Power supply/Consumption (12~24)VDC/<0.5W(non-cleaning mode)
Material Titanium alloy, stainless steel, POM
Weight/Siz 0.5kg / 160mm×φ40mm

Competitive Advantage

◆ Adopt high brightness LED as light source, which can work stably for a long time

◆ Unique optical and electronic filtering technology is used to eliminate the influence of ambient light on measurement.

◆ The cleaning brush automatically cleans, greatly reducing maintenance workload
