chlorophyll a sensor josa chla-0
Place of Origin: China
Brand Name: JIDE
Model Number: JOSA-ChlA

Description

JOSA-ChlA is an online water quality analyzer developed based on the JOSA optical water quality analysis platform. Highly sensitive photoelectric sensors capture weak fluorescence signals and convert them into chlorophyll a/algae density. Digital and intelligent sensor design concept.

Specifications

Model JOSA-ChlA
Measurement parameters Chlorophyll a, temperature
Measurement method Fluorescence method
Range Chlorophyll a: (0~50/500) μg/L;Temperature: (0~60) ℃
Accuracy ≤±3%
Repeatability ≤2%
Resolution 0.01μg/L
Detection limit 0.05μg/L
Response time ≤10s
Drift ≤±1%F.S.
Calibration cycle 6 months
Protection level IP68
Cleaning method Mechanical brush automatic cleaning
Communication RS485 (ModbusRTU), maximum baud rate 115200bps
Power supply/Consumption (12~24)VDC/<0.5W(non-cleaning mode)
Material Titanium alloy, stainless steel, POM
Weight/Siz 0.5kg / 160mm×φ40mm

Competitive Advantage

◆ Adopt high brightness LED as light source, which can work stably for a long time

◆ Unique optical and electronic filtering technology is used to eliminate the influence of ambient light on measurement.

◆ The cleaning brush automatically cleans, greatly reducing maintenance workload
