online fluoride ion selective analyzer jisa flouri-0
Place of Origin: China
Brand Name: JIDE
Model Number: JISA-FlourI

Description

JISA is an online water quality analyzer developed based on a digital water quality analysis platform. It can accurately monitor most of the water quality ion parameters required by the market. It uses industrial online ion selective electrodes and digital and intelligent sensor design concepts. The instrument implements electrode signal detection, pH compensation, temperature detection and automatic compensation.

Specifications

Model JISA-ChloriI
Measurement parameters Chloride ion, pH, Temp
Measurement method Ion Selective Electrode Method
Range Ion concentration: (0.1~1000) mg/L; pH: 0~14; Temperature: (0~60)℃
Accuracy ≤±3%
Repeatability ≤2%
Resolution Ion concentration: 0.01mg/L, pH: 0.01
Detection limit 0.1mg/L
Response time ≤60s
Zero drift/quantity drift (24h) ≤±3%F.S.
Calibration cycle 3 months
Temperature range (0~60)℃
Protection level IP68
Communication RS485 (ModbusRTU), maximum baud rate 115200bps
Power supply/Consumption (12~24)VDC/<0.5W
Material Stainless steel, POM
Weight/Size 0.6kg / 205mm×φ45mm

Competitive Advantage

◆ Imported ion bulb sensitive membrane element, can work stably for a long time

◆ pH and temperature compensation are standard to meet high precision requirements and provide accurate readings

◆ Detachable design, consumables can be replaced independently, extending the service life of the whole machine and convenient
